1 POLE 32A O-I-II 2 CONTACT SWITCH
The PR ONE cam switch line:
Key features:
- 45 degree switch-over angle.
- Switches with two ways as well as OFF.
- Contacts that were forced to open.
- Meets the criteria for load breaks up to 690V.
- Finger protection at the IP20 rear terminal and front protection at IP40.
Specifications
- SERIES: PR ONE.
- CONTACT RATING AC-21: 32A.
- CONTACT RATING AC-23: 11 KW.
- NUMBER OF POLES: 1 pole.
- DESCRIPTION: 2-way rotary cam switch.
- ACTION: (O-I-II).
- OPERATING TEMPERATURE: -20°C to 70°C.
- FRONT BEZEL: 48 mm - engraved aluminium plate with black handle.
- STANDARDS OF COMFORMITY: IEC EN 60947-1, 60947-3, UL508, UL-CSA.
| Brand | BACO |
|---|
