11kW 3-Ph 380VAC IP-54 Heavy Duty DBU RS-485 Keypad

ZAR 27,604.00
Out of stock
SKU
SV0110IS7-4SP

iS7 Series:

  • With its improved V/F control, V/F PG slip compensation, and sensor-less vector control, the iS7 produces more effective performance.
  • The iS7 places a strong emphasis on its user-friendly interface and environmentally friendly features, which include support for macro groups and wide graphic LCD keypad users, as well as electro-thermal motor protection and input/output phase loss protection.
  • A speed-precision-driven vector algorithm and a competitive and strong low-speed torque control are features of iS7 technology.
  • Range of speed control: 100:1.
  • Very low torque control capability: actual torque of 150% at 0.1 Hz.
  • Maximum torque control capacity inside the range of restoration

Specifications:

  • Series: IS7
  • Input Range VAC: 380 to 480 Volts AC
  • Input Phase: 3
  • HP: 7.5 Horsepower
  • Amps: 22 Amps
  • Braking Type: DJ Injection
  • Operator Controls: Built In
  • Mounting: DIN Rail
  • Amps (Constant Torque Rating): 24 A
  • Amps (Variable Torque Rating): 22 A
  • NEMA Rating: NEMA 12
More Information
Brand LS Electric
