12~24V DC supply 16x DC In 16x Rly out PS2/USB loader 1 Ch RS-232C
Specifications:
- Weight: 600gr
- Current Consumption: 660mA
- Supply voltage: 12~24 VDC
- Output Type: Digital Relay (DC 24V/AC 220V)
- Categories: XEC High Performance PLC, Max 10 Exp Cards, 384 I/O Points, HSC, RTC, Pos Func
- IEC 61131 PLC, 12/24V DC or 100-240V AC, USB, 83 n/s Step, HSC, RTC. Pos
Input Specifications:
- Input points: 16.
- Rated input voltage: DC 12/24V
- Rated input current: 5/10mA (contact 0~7: 7/15Ma)
- Operation voltage range: DC 9.5~30V (Ripple rate <5%)
- On voltage/On current: DC 9V or more/3mA or more
- Off voltage/Off current: DC 5V or less/1mA or less
- Input resistance: 2.7KΩ
| Brand | LS Electric |
|---|
