12 x 24V DC In 8 x PNP Out PS2/USB loader 1 Ch ea RS-232 and RS-485 HSC
Description:
- The micro-PLC that provides maximal automation at the lowest possible cost is the XGB series.
- With its excellent functionality and performance, it can handle tasks ranging from easy control to difficult ones.
- XGB has a user-friendly interface along with multiple network monitoring and diagnosis features, as well as a backup function.
Integrated programming environment
- Improved user interface with XG-PD and XG5000
- Several types of monitoring.
- Monitoring and diagnostics of networks.
Optimum communication environment
- Strong communication: integrated RS-232C/485, two communication expansions, Ethernet, and Cnet I/F network configuration.
Specifications:
- AC110/240V power supply
- Relay output rating: 2A Resistive.
- Max. I/O points: 384
- Analogue input resolution: 14-bit
- Analogue output resolution: 14-bit
- 12 DC24 input
- 8 Transistor (Source) output
- 2 option slots
- Processing speed: 94ns/Step
- Program capacity: 15Kstep / 200KB.
- Max. I/O points: (Main + Expansion 7 stages) 254 points
- RS-232C / RS-485(2 channel) Pulse catch.
- Input filter External interrupt.
- Size: 135 x 64 90 mm
- PID control High-speed counter Positioning Categories
- XBC-SU Standard PLC (Master-K), Max 7 Exp Cards, 2x Option Mod
- Master-K PLC, 100-240V AC, USB, 90 n/s Step, Max 7 Exp. Cards & 2x XBO Options, HSC, Pos
Key benefits:
- Compact
- Cost-effective
- LADDER and IEC-1131 programmable.
- From 38 to 284 I/O points
- From 94 ns/step to 240 ns/step
- From 4 to 200 K steps
| Brand | LS Electric |
|---|
