120 WAY SURFACE MOUNTING DISTRIBUTION BOARD 2x EMPTY ROWS
Distribution boards for surface and flush mounting in the Vega D series (IP41 when doors are installed):
- Installing Vega D enclosures for supply up to 250A is appropriate for both residential and commercial structures.
- Supplied in an assembly-ready state.
- There are 24 module rows in each enclosure.
Features:
- Enclosure for metallic surface mounting.
- Quick-connect earth connections that are integrated.
- Front frame that can be removed for best access to installed internal devices.
- Doors made of sheet metal (without a window or with one) must be purchased individually.
Boards for surface mounting:
- Top and bottom plates that can be removed for simpler cable entrance are included without the top two rows.
- To be finished with internal modules of choice that can include a chassis plate, two rows of modular devices, or a main switch MCCB (up to 250A).
- Vega D series
- 120 modular ways in all (5 x 24).
- DESCRIPTION: Index Protection Surface Mounting Distribution Board IP: IP30/IK07 (door-less) - IP41/IK08 (door-filled) - class II completely sealed
- COLOR: Pale gray 9010 RAL
- DIMENSIONS (MM): 193 x 550 x 900 (H) x W
| Brand | :hager |
|---|
