12A 12-280VAC 600V SOLID STATE RELAY
Solid state relays (SSR):
- With an extremely long lifespan and back-to-back thyristors, all Celduc SSRs (solid state relays) use 4th generation TMS2 technology.
General features:
- LED status control.
- Input current that is regulated.
- Safeguard against input overvoltage.
- Resistive load SO9 range (AC-51).
- Zero-cross switching with a resistive load in mind.
- EMC appropriate for an industrial setting.
- As per IEC/EN 61000-4-4 (bursts) and IEC/EN 61000-4-5 (spikes), extremely high immunity.
Specifications:
- SERIES: SO9
- SWITCHING CURRENT: 12A
- SWITCHING VOLTAGE: 12 - 280 VAC
- PEAK VOLTAGE: 600V
- CONTROL VOLTAGE: 3 - 32 VDC
- DESCRIPTION: Zero-cross for resistive loads
- INDEX PROTECTION IP: IP20
- DIMENSIONS (MM): (H) 59.4 x (W) 45 x (D) 30
| Brand | Celduc relais |
|---|
