16 DI Expansion Unit NON-SAFETY

ZAR 6,288.70
Out of stock
SKU
1100092

MOSAIC - Safety controllers:

  • MOSAIC is a modular safety controller that may be configured to control any aspect of a machine or plant's safety.
  • Composed of a master unit that can manage up to 14 extension units in a system or function as a stand-alone device.

Capable of monitoring several safety sensors and signals such as:

  • Light curtains.
  • Photocells.
  • Laser scanners.
  • Emergency stops.
  • Electromechanical switches.
  • Safety door switches.
  • Magnetic switches.
  • Safety mats and edges.
  • Two-hand controls.
  • Hand grip switches.
  • Encoders and proximities for safety speed control.
  • Load cells.
  • Pressure switches.
  • Temperature, flow and level measurements.

General features:

  • Power supply: 24V DC ± 20%.
  • Safety level: SIL 3, PL e, SILCL 3, Cat. 4.
  • Connections: Removable (screw terminal) blocks.
  • Mounting: DIN rail mounting according to EN 50022-35 standard.

MOSAIC - Expansion modules.

  • Input/output expansion modules: Provides additional digital inputs and outputs to the master unit.
  • Status outputs: Provides additional non-safety outputs to the master unit.
  • Safety relays: Provides safety relay outputs with guided contacts.
  • Communication: For connection to the most common industrial Field-bus systems.

Specifications:

  • SERIES: Mosaic.
  • DESCRIPTION: 16x programmable digital (non-safety) signal outputs.
  • OPERATING TEMPERATURE: -10 ... 55 °C.
  • STORAGE TEMPERATURE: - 20 ... 85 °C.
  • SAFETY LEVEL: Safety level: SIL 3 mm SILCL 3 mm PL e mm Cat. 4.
  • MOUNTING: DIN rail mounting.
  • DIMENSIONS (MM): (H) 99 x (W) 22.5 x (D) 114 mm.

Technical data:

  • Safety level (SIL / PL): SIL 1 - SILCL 1 - PL c.
  • Connections: Removable terminal blocks, screw contacts.
  • Power supply (VDC): 24 ± 20%.
  • Degree of protection: IP 20 for housing - IP 2X for terminal block.
  • Operating temperature (°C): From -10 to 55.
  • Storage temperature (°C): from -20 to +85.
  • Programmable signalling outputs: 16 PNP 100 mA.
  • LED signalling: Input/output status and fault diagnostics.
  • Connection with MSC BUS.
  • Fastening: Rail fastening according to EN 50022-35 standard.
More Information
Brand Reer
