185 kW 323A FLC Standard Economic-Type 200 - 525 Vac Supply 110 - 440 Vac

ZAR 85,811.00
Out of stock
SKU
SSMe-0397B-V5-C1

Description:

  • A soft starter is a practical and affordable way to ensure the motor runs steadily.
  • With LS's extensive experience and knowledge, we offer a solution to raise operating efficiency and reduce energy costs.

Features:

  • Easy Operation and Control
  • Motor Protection
  • Built-in bypass
  • Compact Design, Easy to integrate.
  • Timed Voltage Ramp System
  • Convenient Status and Trip Check with LED Indicator

Specifications:

  • 185kW Soft Starter
  • Normal duty: 185 kW 323A 400 V AC
  • Heavy duty: 150 kW 263A 400 V AC
  • Economic
  • Digital Control
  • 397A FLC
  • Built-in Bypass Contactor
  • Input Voltage 200 ~ 525V AC
  • Control Voltage 110 ~ 120 and 220 ~ 240V AC
  • Main Voltage: 110~120 and 220~240 V AC
  • Analog Settings
  • Without Motor Protection
  • IP00
  • Size: 216 x 523 x 243 mm (W x H x D)

SSM Series:

  • Zero Harmonics on Smart Cards
  • System Protection: Power Through minimizes on-site downtime while allowing for continued operation in emergency scenarios.
  • Both still have the greatest capacity for protection and control.
  • Design with the System's Total Efficiency in Mind: Choosing the right motor control mode is just as crucial as using energy-efficient components.
  • It is more effective to use a soft starter rather than a VFD when operating at a fixed speed.
  • Effective Function: SSM Soft Starters operate at 99.5% efficiency when powered by an internal bypass.
  • Graphical Display
  • Simple commissioning through fast application setup
  • Support for eight languages, including English, Portuguese, Chinese, French, Spanish, Italian, German, and Russian, is multilingual.
  • Six network connections make for a strong network connection. Modbus TCP/PROFINET/Ethernet IP/Profibus/Device Net/Modbus RTU
  • Automated Schedulers and Timers: Quick and easy automation that does not require timers or additional logic.
  • Simulation Mode: No need to connect the main power supply and motor; easy and fast testing during installation and commissioning.
More Information
Brand LS Electric
