Specifications:

• Inverter output voltage: 3 x 400V AC
• Voltage between phases (for three phase system): 3 x 380...480V AC
• Voltage output: 0...12V DC
• Mounting: DIN rail mounting and wall mounting
• Number of inputs: 5
• Number of analog inputs: 1
• Operating temperature: -10...50°C
• Output frequency: 0...400Hz.
• Current rating: 6.1A
• Number of analog outputs: 1
• Dual rating: 2.2kW/5.5A Heavy Duty-150% Overload/1 min 3kW/6.9A Normal Duty-120% Overload/1 min
• 3 Phase Input 3 Phase Output
• 380-480 Volts
• Control modes: U/f Slip compensation Sensor less vector IM.
• Output frequency: 0.1 - 400 Hz - U/f 0-120 Hz - IM Sensor less.
• LED Keypad
• Built-in EMC filter(C3)- Industrial
• BRAKE CHOPER BUILD IN
• PNP / NPN logic
• Standard IO - control terminal I/O 5mm pitch
• Dual motor parameters KEB function
• PID controller
• RS 485 interface-LS Bus / Modbus RTU
• Drive View Software
