2 Channel Analogue output (Voltage/Current) 12-Bit Resolution
Features:
- To control and keep an eye on temperature measurements, use PLCs of the "E" and "SU" types.
- Module accepts either Current or Voltage output.
- LS Electric Agency Approved: UL, cUL, CE.
Specifications:
- Number of channels: 2
- Voltage Range: 0 to 10VDC (Input Resistance: 1MΩ minimum)
- Current Range: 4 to 20mA, 0 to 20mA (Load 450Ω or less)
- Setting Range: In User Program or I/O Parameter per Channel
- Signal Resolution: 12 bits.
- Maximum Conversion Speed: 1ms / Channel + Scan Time
- Analogue Input/Output: 2 Channel A/V Output
- Output Type: Analogue DC 0~10V /4~20mA /0~20mA.
- Product Category: Compact PLC (XGB)
- Product Type: Option Board
- XBM / XEC-E and SU Type Clip-in Option Modules
| Brand | LS Electric |
|---|
