25A 12-275VAC 600V SS RELAY
SSRs, or Solid-State relays:
- Every Celduc SSR (solid state relay) has a very long lifespan and is equipped with back-to-back thyristors and 4th generation TMS2 technology.
General Features:
- Manage the LED status.
- Controlled input current.
- EMC suitable for use in an industrial setting.
- Most load types (lamps) fall within the SO8 range.
- Protection against voltage on the input (transil) and output (VDR).
- Zero-cross switching at a low threshold for zero-crossing (<12V).
- Extremely high immunity as defined by IEC/EN 61000-4-5 (spikes) and 61000-4-4 (bursts).
Specifications:
- SERIES: SO8
- SWITCHING CURRENT: 25A
- SWITCHING VOLTAGE: 12 - 275 VAC
- PEAK VOLTAGE: 600V
- CONTROL VOLTAGE: 20 - 265 VAC/DC
- DESCRIPTION: Zero-cross for most loads
- INDEX PROTECTION IP: IP20
- DIMENSIONS (MM): (H) 59.4 x (W) 45 x (D) 30
| Brand | Celduc relais |
|---|
