25A 12-280VAC 600V SOLID STATE RELAY
Solid state relays (SSR):
- Back-to-back thyristors and 4th generation TMS2 technology, which has an extremely long lifespan, are features found in every Celduc SSR (solid state relay).
General features:
- Manage the LED status light.
- Input current that is controlled.
- Protection from input overvoltage.
- Resistive loads in the SO9 range (AC 51).
- Zero-cross switching made especially to work with resistive loads.
- In an industrial setting, EMC compliant.
- IEC/EN 61000-4-4 (bursts) and IEC/EN 61000-4-5 (spikes) both confirm very good immunity.
Specifications:
- SERIES: SO9
- SWITCHING CURRENT: 25A
- SWITCHING VOLTAGE: 12 - 280 VAC
- PEAK VOLTAGE: 600V
- CONTROL VOLTAGE: 3 - 32 VDC
- DESCRIPTION: Zero-cross for resistive loads
- INDEX PROTECTION IP: IP20
- DIMENSIONS (MM): (H) 59.4 x (W) 45 x (D) 30
| Brand | Celduc relais |
|---|
