3 PHASE VOLTAGE COMPARATOR 525VAC
Description:
- Comparison of the voltage window and phase failure.
- Compact modular modules in the Electro D series of control and timing devices make it simple to integrate them into distribution boards or standard panels.
- They align with ordinary tiny circuit breakers (MCBs) and attach straight onto DIN rail.
Features:
- Monitors own supply.
- Optional latch facility.
- 10A SPDT output relay.
- 4 Front face selectable delays.
- Modular 35.5mm DIN rail mountable.
- LED indication for power supply ON.
- Over/under voltage monitoring / reversal.
- High resolution analogue microprocessor.
- LED indication for over and under voltage.
- Front face adjustable over and under voltage levels.
- Delays: No delay, startup delay 10 second,180 second recovery delay, reaction delay 10 second.
Three phase electronic timer with reversal:
- CONTACT: 10A SPDT.
- PHASE: Three phases.
- DELAYS: No delay, startup delay 10 second,180 second recovery delay, reaction delay 10 second.
- INPUT: Pin 1, 5 & 9 L1, L2 & L3.
- RATED CURRENT: 10A.
- RATED VOLTAGE: 250V.
- MECHANICAL LIFE: 10x106 cycles.
- PROTECTION INDEX IP: IP 20.
- OPERATING TEMPERATURE: -10 to + 50°C.
- STORAGE TEMPERATURE: -50 to + 85°C.
- DIMENSIONS (MM): (H) 92 x (W) 36 x (D) 64.
| Brand | Electrodev |
|---|
