Technical Data:

Phase Failure:

• Fixed Delay Time: 500ms

Adjustable/Fixed Unbalanced Protection:

• Range/Limit: ± (5% => 20%)/OFF
• Hysteresis: 3% x Un ≈ 12 VAC
• Delay Time: 0.1=>; 10s

Adjustable Voltage Protection:

• Upper Limit: + (5% => 20%)/OFF
• Lower Limit: -(5% => 20%)/OFF
• Hysteresis: 6 VAC
• Delay Time: 0.1=>10s for off delay operation

Auxiliary Contacts:

• Type: 1 C/O (SPDT)
• Max. Ratings - AC (for NO Side): 10A/250V; 1250 VA
• Max. Ratings - DC (for NO Side): 5A/30VDC; 150W
• Mechanical Lifetime: 107 operations
• Electrical Lifetime Operations (for NO Side): 5×104 (5A at 250VAC) 1×105 (5A at 30VDC)

Supply Voltage:

• AC: 380-480VAC ±25% from L1-L3

Ambient Conditions:

• Operating Temperature: -20 to +60 °C
• Storing Temperature: -40 to +75 °C
• Relative Humidity (No Condensation): Max.95%
• Power Consumption: AC: 4VA

Mounting Type:

• EMC-EMI: OK
• Packing Unit: 1
• Weight (g): 66
