40A 12-280VAC 600V SOLID STATE RELAY
Solid state relays (SSR):
- Every Celduc solid state relay (SSR) has a very long lifespan and is equipped with back-to-back thyristors and 4th generation TMS2 technology.
General features:
- Manage the LED status.
- Controlled input current.
- Protection against input overvoltage.
- SO9 range (AC-51) for resistive loads.
- Zero-cross switching made especially for loads that are resistive.
- EMC appropriate for use in an industrial setting.
- Very high immunity as defined by IEC/EN 61000-4-5 (spikes) and 61000-4-4 (bursts).
Specifications:
- SERIES: SO9
- SWITCHING CURRENT: 40A
- SWITCHING VOLTAGE: 12 - 280 VAC
- PEAK VOLTAGE: 600V
- CONTROL VOLTAGE: 3 - 32 VDC
- DESCRIPTION: Zero-cross for resistive loads
- INDEX PROTECTION IP: IP20
- DIMENSIONS (MM): (H) 59.4 x (W) 45 x (D) 30
| Brand | Celduc relais |
|---|
