50A 24-510VAC 1200V SS RELAY
Solid state relays (SSR):
- Back-to-back thyristors and 4th generation TMS2 technology, which has an extremely long lifespan, are features found in every Celduc SSR (solid state relay).
General features:
- Manage the LED status light.
- Input current that is controlled.
- In an industrial setting, EMC compliant.
- Lights and infrared loads are within the SO8 range.
- Input (transil) and output (VDR) voltage protection.
- Zero-cross switching at low zero-crossing voltages (<12V).
- IEC/EN 61000-4-4 (bursts) and IEC/EN 61000-4-5 (spikes) both confirm very good immunity.
Specifications:
- SERIES: SO8
- SWITCHING CURRENT: 50A
- SWITCHING VOLTAGE: 24 - 510 VAC
- PEAK VOLTAGE: 1200V
- CONTROL VOLTAGE: 20 - 265 VAC/DC
- DESCRIPTION: Zero-cross for most loads
- INDEX PROTECTION IP: IP20
- DIMENSIONS (MM): (H) 59.4 x (W) 45 x (D) 30
| Brand | Celduc relais |
|---|
