Specifications:

• Main voltage: 380~690VAC (± 10%).
• Control voltage: 24VAC/VDC (±20%), 2.8A.
• Main frequency: 50~60Hz (±5Hz).
• Rated insulation voltage to earth: 600VAC.
• Rated impulse withstand voltage: 6KV.
• From designation: Bypassed or continuous, semiconductor motor starter form 1.
• Short circuit capability: coordination with semiconductor fuses (Type 2), Coordination with HRC fuses (Type 1).
• EMC immunity: IEC 60947-4-2.
• EMC emissions: NIEC 60947-4-2 class B.
• Input Rating: Active 24 VDC, 8mA approximately.
• Motor Thermistor: Trip > 3.6kΩ, Reset < 1.6kΩ.
• Relay outputs: 10A at 250VAC Resistive, 5A at 250VAC AC15 pf 0.3.

SSM Series:

• Zero Harmonics on Smart Cards
• System Protection: Power Through minimizes on-site downtime while allowing for continued operation in emergency scenarios.
• Both still have the greatest capacity for protection and control.
• Design with the System's Total Efficiency in Mind: Choosing the right motor control mode is just as crucial as using energy-efficient components.
• It is more effective to use a soft starter rather than a VFD when operating at a fixed speed.
• Effective Function: SSM Soft Starters operate at 99.5% efficiency when powered by an internal bypass.
• Graphical Display
• Simple commissioning through fast application setup
• Support for eight languages, including English, Portuguese, Chinese, French, Spanish, Italian, German, and Russian, is multilingual.
• Six network connections make for a strong network connection. Modbus TCP/PROFINET/Ethernet IP/Profibus/Device Net/Modbus RTU
• Automated Schedulers and Timers: Quick and easy automation that does not require timers or additional logic.
• Simulation Mode: No need to connect the main power supply and motor; easy and fast testing during installation and commissioning.
