Specifications:

• Material:
• Glass-reinforced polyester.
• Colour: Light grey (RAL 7035).
• Surface Treatment: Untreated.
• Construction:
• Fully welded construction for enhanced strength and durability.
• Plain door with a lock using a male triangular wrench.
• Interlockable door with two key locks.
• Suitable for wall mounting.
• Protection:
• Ingress Protection: IP66, ensuring excellent protection against dust and water.
• Impact Resistance: IK10.
• Insulation Class: II.
• Dimensions:
• Height: 800 mm.
• Width: 600 mm.
• Depth: 300 mm.
• Internal Depth: 300 mm.
• Thickness of Sidewall Material: 2 mm.
• Technical Data:
• Rated Current: 630 A.
• Number of Modules: 140.
• Number of Rows: 4.
• Number of Rails: 5.
• Number of Openings for Flange Plates: 0.
• Standards: IEC 62208.
• Temperature Range: Suitable for a wide range of temperatures, ensuring reliability in various environments.
• Applications: Suitable for outdoor use and environments such as the food industry or medical environments where aggressive detergents are used for cleaning.
