96 WAY SURFACE MOUNTING DISTRIBUTION BOARD 2x EMPTY ROWS
Distribution boards for surface and flush mounting in the Vega D series (IP41 when doors are installed):
- Installing Vega D enclosures for supply up to 250A is appropriate for both residential and commercial structures.
- Supplied in an assembly-ready state.
- There are 24 module rows in each enclosure.
- Surface-mounting enclosure made of metal.
- Quick-connect earth terminals that are integrated.
- Front frame is detachable for best access to fitted internal electronics.
- Sheet metal doors (without a window or with one) must be purchased separately.
Surface-mounting boards:
- Easily accessible cable entry with detachable top and bottom plates provided without the upper two rows.
- To be finished with internal modules of choice that can include a chassis plate, two rows of modular devices, or a main switch MCCB (up to 250A).
- SERIES: Vega D
- NO OF MODULAR WAYS: 96 (4 x 24)
- DESCRIPTION: Surface mounting distribution board
- INDEX PROTECTION IP: IP30/IK07 (without door) - IP41/IK08 (with door) - class II totally insulated.
- COLOUR: Light grey RAL 9010
- DIMENSIONS (MM): (H) 750 x (W) 550 x (D) 193
Brand | :hager |
---|
