AAP14 2.5 LI-LI

ZAR 84.67 ZAR 73.63
Out of stock
SKU
1988230000

Description:

  • Any kind of machine can be fitted with the special modular concept.
  • Because of their homogeneous design and two different constructions alternating or grouping the potential distribution terminal blocks of AAP are successful.
  • In the grouped structure of the control voltage distribution, the potentials are arranged on distinct terminal blocks, forming whole potential blocks.

Specifications:

  • Version: Modular distribution terminals, PUSH IN.
  • Quantity: 50.
  • Depth: 53.5 mm.
  • Depth including DIN rail: 54 mm.
  • Height: 94 mm.
  • Width: 5.1 mm.
  • Storage temperature: -25 °C...55 °C.
  • Continuous operating temp., min.: -60 °C.
  • Continuous operating temp., max.: 130 °C.
  • Material: Wemid.
  • Color: dark beige.
  • Color of operational elements: red/blue.
  • UL 94 flammability rating: V-0.
  • Installation advice: Rail.
  • Open sides: right.
  • Non-snap-on.
  • Type of fixing: snap-on.
  • Type of mounting: TS 35.
  • No snap-in pegs.

System specifications:

  • End cover plate required.
  • Number of potentials: 2.
  • Number of levels: 1.
  • Number of clamping points per level: 4.
  • Number of potentials per tier: 2.
  • No Levels cross-connected internally.
  • No PE connection.
  • Rail: TS 35.
  • No N-function.
  • No PE function.
  • No PEN function.

Rating data:

  • Rated cross-section: 2.5 mm².
  • Rated voltage: 500 V.
  • Rated DC voltage: 500 V.
  • Rated current: 24 A.
  • Current at maximum wires: 24 A.
  • Standards: In accordance with IEC 60947-7-1.
  • Volume resistance according to IEC 60947-7-x: 1.33 mΩ.
  • Rated impulse withstand voltage: 6 kV.
  • Power loss in accordance with IEC 60947-7-x: 0.77 W.
  • Pollution severity: 3.
More Information
SKU 1988230000
Brand Weidmuller
