AC Input choke EM-RAI3-600
Pricing available on request
EM-RAI3 Series Input Choke:
- Rated working voltage: AC 3/380V~480V.
- Tolerance voltage test: 3.5KV, AC/50Hz/5mA/60s.
- Application of frequency: 0~60Hz.
- Power: 0.4~600KW.
- Working noise: <55dB.
- Dimension (mm) K x S x G x A x B x L*Z: 435 x 317 x 363 x 240 x 187 x 14*24.
- Insulation resistance: 1000VDC: >100MOhm.
Specifications:
- Rated Power (KW): 600.
- Rated Current (A): 1250.
- Insulation class: F.
- Housing: T4.
| Brand | EMHEATER |
|---|
