Properties:

• A redundant power supply can be set up using two power-feed units and two separate power supplies.
• The device can be used in safe (non-explosive-risk) areas or in Zone 2 or Division 2.
• Two green LEDs indicate the operating status of the power supply and the backup power supply.
• The power-feed unit ACT20-FEED-IN-PRO-S detects errors on each of the devices mounted on the Weidmueller CH20M DIN rail and sends a collective message to an external controller via the internal status relay.
• A red LED indicates a fault.
• When these circumstances are satisfied, the status relay is turned on.
• The connection terminals 51 and 52 have a supply voltage.
• The terminals 53 and 54 are home to the backup supply voltage.
• Insert the included jumper between terminals 52 and 53 if the backup power supply is not needed.
• There are no errors reported by the devices mounted on the Weidmueller DIN rail.

Specifications:

• Version: Supply module, Distributes supply voltage to rail bus, Optional connection of backup supply.
• Depth: 113.6 mm.
• Height: 117.2 mm.
• Width: 22.5 mm.
• Storage temperature: -20 °C...85 °C.
• Operating temperature: -20 °C...60 °C.
• Humidity: 40 °C / 95 % rel. humidity, no condensation.
• Power consumption: ≤ 2 W.
• Protection degree: IP20.
• Rail: TS 35, CH20M Bus.
• Voltage supply: 21.6...26.4 V DC.

Input:

• Backup power supply: 21.6...26.4 V DC.
• Input current: max. 4 A.
• Input voltage: 21.6…26.4 V DC.
• Number of inputs: 2.
• Supply voltage (input): 21.6...26.4 V DC.
• Trigger level for the power supply: Fault <21 V DC.

Output:

• Number of outputs: 1.
• Output current: Equivalent to input current, max. 4 A.
• Output power: 96 W.
• Output voltage, note: Input voltage -0.5 V DC / 4 A.
• Supply voltage (output): 24 V DC.

Digital output:

• AC power, max.: 500 VA / 60 W.
• Alarm function: Device error, Failure of power supply, backup power supply.
• Continuous current: 2 A.
• Max. switching voltage, AC: 250 V.
• Type: Relay, 1 CO contact.
