ACT20X-HAI-SAO-S
Description:
- Ex-supply isolator for standard DC current signals, a two-channel, transparent HART supply isolator with an external power supply of 22.5 mm in width.
- It can be used to transmit and isolate standard signals ranging from 4 to 20 mA from Ex Zones 0, 1, and 2 to the safe zones.
- The input to the component is both active and passive.
- More than 15 VDC can be given to external sensors.
- There are two ways to run the 4...20 mA output circuit: passively and strongly.
- Through a relay contact, status and error messages can be obtained (NO).
- The component can be set up with the help of common FDT and DTM software.
- Extra housing for mounting on TS35 rails.
- Dimensions: screw connection; nominal cross-section: 2.5 mm2; L/W/H: 119.2/ 22.5/ 113.6.
- IP 20 is the protection level.
- Sensor supply input 4...20 mA > 15 V DC.
- Passive output: 4...20 mA active 26 V DC maximum current loop of 4...20 mA
- Load less than 600 Ohm
- Precision: <0.1% v.E.
- Coefficient of temperature: <0.01% v.E./°C (Tu)
- Relay for alarm output 1: No communication Safe zone: 250 V AC/30 V DC @ 2A Zone: 32 V DC @ 1 A/32 V AC @ 0.5 A 2 Voltage differential of 19–31.2 V DC
- Loss of power of about 1.8 W
- Range of ambient temperature: -20 °C to +60 °C
- cULus, ATEX, IECEX, FM ATEX marking II 3 G ExnA nC IIC T4 ATEX characteristic data; Secure isolation EN 61010, 3-way isolation up to 2.6 kV AC/DC of all circuits against each other; Working voltage: 300 V AC/DC at overvoltage category II and pollution degree 2; approvals: I0 = 93 mA DC, P0 = 650 mW, and U0 = 28 V DC.
Specifications:
- Version: EX signal isolating converter, Ex-input: 4 - 20 mA, Safe-output: 4-20mA, 1-channel.
- Depth: 113.6 mm.
- Height: 119.2 mm.
- Width: 22.5 mm.
- Storage temperature: -20 °C...85 °C.
- Operating temperature: -20 °C...60 °C.
- Humidity: 0...95 % (no condensation).
- Mounting position: horizontal or vertical.
- Rail: TS 35.
- Type of mounting: Snap mounting support rail.
- Accuracy: <0.1% span.
- Configuration: With FDT/DTM software, Requires configuration adapter 8978580000 CBX200 USB.
- Power consumption: ≤ 1.0 W.
- Protection degree: IP20.
- Step response time: ≤ 5 Ms.
- Temperature coefficient: <0.01% of span/°C (TU).
- Type of connection: Screw connection.
- Voltage supply: 19.2…31.2 V DC.
- Rated voltage: 300 V.
- Insulation voltage: 2.6 kV (input / output).
Input EX:
- Input frequency: 4…20mA.
- Output signal in case of wire break: <1 mA.
- Residual ripple (current loop): <7.5 mV eff.
- Sensor supply: > 16 V DC.
- Type: intrinsically safe circuit, active (as current source) or passive (as current sink).
- Voltage drops not powered: <6 V.
- Voltage drops powered: <4.5 V.
Output:
- Load impedance current: ≤ 600 Ω.
- Load stability: ≤ 0.01 % of end value / 100 Ω.
- Output current: 4...20 Ma.
- Output signal limit: <28 mA.
- Type: active (as current source) or passive (as current sink).
Alarm output:
- Alarm function: Signal limit exceeded, Line interruption at the input, No supply voltage, Device error.
- Continuous current: ≤ 0.5 An AC / 0.3 A DC (safe zone), ≤ 0,5 An AC / 1 A DC (zone 2).
- Nominal switching voltage: ≤ 125 V AC / 110 V DC (safe area) ≤ 32 V AC / 32 V DC (zone 2).
- Power rating: ≤ 62.5 VA / 32 W (safe area) ≤ 16 VA / 32 W (Zone 2).
- Type: Status relay, 1 NC (voltage-free).
| Brand | Weidmuller |
|---|
