ASK 61.4 1000/5A 15VA CT cl 1

ZAR 521.71
Out of stock
SKU
19076

General standards for current transformers:

  • Type of isolation: E
  • The maximum operational voltage is < 0.72 kV, and the nominal frequency is 50Hz (alternative frequencies can be requested).
  • Thermal short-time current nominal: Ith = 60 x In
  • FS 5 serves as the over-current limiting factor up to 1500 A nominal current.
  • MBS AG current transformers fully abide with: IEC 61869/1+2 - VBG 4 - DIN 42600 - DIN VDE 0414/1

Specifications:

  • Busbar mounted current transformers(5A secondary - class 1)
  • ASK 61.4 current transformers
  • MODEL: ASK 61.4
  • RATIO: 1000/5A
  • ROUND CONDUCTOR (⌀): 44 mm
  • PRIMARY BAR CONDUCTOR: 60 X 10 / 50 X 20 mm
  • DESCRIPTION: Standard current transformer
  • CLASS: 1
  • VA: 30
  • DIMENSIONS (MM): (H) 106 x (W) 96 x (D) 58
More Information
Brand MBS
