CLI C 2-4 VI/SW 7 MP

ZAR 0.00
Out of stock
SKU
0251311524

Conductor and cable markers:

  • Conductor O.D.: 4 - 10 mm.
  • Conductor O.D., max.: 10 mm.
  • Conductor O.D., min.: 4 mm.
  • Conductor cross-section, max.: 16 mm².
  • Conductor cross-section, min.: 2.5 mm².
  • Cross-section for connected wire: 2.5 - 16 mm².

Specifications:

  • Version: Cable Line, Conductor and cable markers, violet.
  • Depth: 8 mm.
  • Height: 4 mm.
  • Width: 7 mm.
  • Operating temperature: -30...80 °C.
  • Colour: violet.
  • Colour of printing: white.
  • Halogen
  • Insulation cross-section, max.: 10.
  • Material: PVC, soft, without Cadmium.
  • Material colour according to resistance code: 7.
  • Number of markers per combination: 1 Component part = Conductor and cable markers.
  • Operating temperature range, max.: 80 °C.
  • Operating temperature range, min.: -30 °C.
  • Orientation of print: horizontal.
  • Printed characters: Numbers.
  • Printing: 7.
  • Printing method: hot embossing.
  • Type of printing: Standard.
  • UL 94 flammability rating: V-0.
  • Multipack.
  • Quantity per pack: 100.
More Information
Brand Weidmuller
