Specifications dimensions and weights:

• Depth: 4 mm.
• Depth (inches): 0.157 inch.
• Height: 3 mm.
• Height (inches): 0.118 inch.
• Width: 3.4 mm.
• Width (inches): 0.134 inch.
• Net weight: 1.4 g.

Temperatures:

• Operating temperature range: -30 - 80 °C.

General data:

• Colour: Yellow.
• Colour of printing: Black.
• Halogen: Yes.
• Material: PVC, soft, without Cadmium.
• Material colour according to resistance code: 4.
• Number per mandrel: 25.
• Operating temperature range: -30 - 80 °C.
• Operating temperature range, max.: 80 °C.
• Operating temperature range, min.: -30 °C.
• Orientation of print: horizontal.
• Printed characters: Upper-case letters.
• Printing: Y.
• Printing method: hot embossing.
• Recommended industries: Process, Machinery.
• Type of printing: Standard.
• UL 94 flammability rating: V-0.
• Version: Multipack.
• Width: 3.4 mm.

Conductor and cable markers:

• Conductor cross-section, max.: 1.5 mm².
• Conductor cross-section, min.: 0.2 mm².
• Conductor O.D.: 1.3 -3 mm.
• Conductor O.D., max.: 3 mm.
• Conductor O.D., min.: 1.3 mm.
• Cross-section for connected wire: 0.2 - 1.5 mm².
• Halogen: Yes.
