CURRENT MONITOR 0-5A 230VAC
Current Monitor:
- Installing the Electro 11 pin plug-in series of control and timing devices is simple and straightforward since they are designed to fit into a conventional 11 pin base.
- This current monitor is an accurate relay for monitoring current under and over.
- The device is perfect for several current monitoring applications because it may be ordered in a variety of AC and DC current ranges.
- Separate potentiometers can be used to modify the hysteresis and set point.
- Additionally, the machine has a latch feature to stop unnoticed malfunctions.
- All units come with a terminating resistor to avoid open circuit in applications that require a CT.
Features:
- Output 10: An integrated SPDT relay latch facility.
- Evaluates individual current input.
- Keeping an eye on the current control relay.
- Adjustable current limitations on potentiometer.
- LEDs for the power supply ON and relay ON.
- Adjustable hysteresis limits via potentiometer.
- Selecting the rear DIP switch for a 10-second startup delay.
- UNDER/OVER current selection via the rear DIP switch.
Specifications:
- DESCRIPTION: Current monitor
- CONTACT: 10A SPDT
- FUNCTION: Over / under current
- HYSTERESIS: 5-50%
- RATED VOLTAGE: 250V
- MECHANICAL LIFE: 10x106 cycles
- PROTECTION INDEX IP: IP 20
- OPERATING TEMPERATURE: -10 to + 50°C
- STORAGE TEMPERATURE: -50 to + 85°C
- DIMENSIONS (MM): (H) 92 x (W) 36 x (D) 64
| Brand | Electrodev |
|---|
