CURRENT MONITOR 0-5A 400VAC

ZAR 1,072.87
Out of stock
SKU
LA55400A

Current Monitor:

  • Installing the Electro 11 pin plug-in series of control and timing devices is simple and straightforward since they are designed to fit into a conventional 11 pin base.
  • This current monitor is an accurate relay for monitoring current under and over.
  • The device is perfect for several current monitoring applications because it may be ordered in a variety of AC and DC current ranges.
  • Separate potentiometers can be used to modify the hysteresis and set point.
  • Additionally, the machine has a latch feature to stop unnoticed malfunctions.
  • All units come with a terminating resistor to avoid open circuit in applications that require a CT.



Features:

  • Output 10: An integrated SPDT relay latch facility.
  • Evaluates individual current input.
  • Keeping an eye on the current control relay.
  • Adjustable current limitations on potentiometer.
  • LEDs for the power supply ON and relay ON.
  • Adjustable hysteresis limits via potentiometer.
  • Selecting the rear DIP switch for a 10-second startup delay.
  • UNDER/OVER current selection via the rear DIP switch.

Specifications:

  • DESCRIPTION: Current monitor
  • CONTACT: 10A SPDT
  • FUNCTION: Over / under current
  • HYSTERESIS: 5-50%
  • RATED VOLTAGE: 250V
  • MECHANICAL LIFE: 10x106 cycles
  • PROTECTION INDEX IP: IP 20
  • OPERATING TEMPERATURE: -10 to + 50°C
  • STORAGE TEMPERATURE: -50 to + 85°C
  • DIMENSIONS (MM): (H) 92 x (W) 36 x (D) 64

More Information
Brand Electrodev
