Specifications:

• Operation Voltage: 10~30VDC/ 24VDC
• Digital Inputs: 2*DI (Isolation) status low: 4VDC
• Analog Inputs: 2*Current (0/4~20mA) +2*PT-100 (Range: -50~+200℃/ Resolution: 0.25℃)
• Digital Outputs: 2*Isolation (Transistor)
• Analog Outputs: 2*AO (0/ 4~20mA)
• Continuous Current: Transistor 1.75A (OCP/ OTP/ UVLO)
• Output Operating Frequency: Transistor: 50KHZ
• RTC/ Hold During Power Off: Yes
• Operation Temperature: -20 to +75 °C
• Communication Ports: USB*1 & RS-485*1
• Communication Baud Rate: 2400~921600bps
• Degree Of Protection: IP20
• Base Controller IOs: 10 IOs
• Installation: 35 mm DIN rail or Flush mounting
• Dimension (W x H x D mm): 76.4*118.2*40.7 mm
• Communication Cable: CAB-MINIUSB60 or RS-485
• *D = LCM Type
