MSO5000HD Series, Digital Oscilloscopes:

• Analog channel bandwidth: 1 GHz, 500 MHz, 350 MHz
• The real-time sampling rate is 5 GSa/s.
• The vertical resolution is 12-bit.
• 4 analog channels and 16 digital channels.
• Memory capacity of up to 500 Mpts.
• The waveform capture rate is up to 800,000 wfms/s (in sequence mode, 2,000,000 wfms/s).
• 9 instrument features include a digital oscilloscope, logic analyser, function/arbitrary waveform generator, spectrum analyser, digital voltmeter, frequency meter, protocol analyser, bode plot analyser, and power analyser.
• Uninterrupted hardware real-time waveform recording and analysis of up to 400,000 frames.
• Up to 4 million points of enhanced FFT.
• 54 different parameter measurements, adds a line graph display and histogram.
• A display with multiple windows.
• 7-digit hardware frequency meter with several channels.
• DVM multi-channel RMS measurement includes DC, AC RMS, and DC+AC RMS.
• Protocol triggering and decoding functions include RS232/UART, I2C, SPI, I3C, 1-wire, CAN, CAN-FD, LIN, Flex Ray, Audio, MIL-STD-1553B, Manchester, SENT, and ARINC429.
• Zone trigger to capture irregular impulses and observe complex signals.
• A 10.1-inch 1280x800 HD capacitive multi-touch display.
• Webserver is integrated.
