Specifications:

• Communication spec: 10/100Base-TX
• Protocol: TCP/IP, UDP/IP
• Service: with LS PLC’s: High-speed link, P2P service, With other devices: P2P service, Application:
• XGT Dedicated protocol server/client, Modbus/TCP Server/client.
• HS link sending/receiving data: 200 words/block (Max. 64 blocks)
• No. of channel connectable to upper stage: 6 channels.
• Service: communication with PC (HMI) and external devices, High-speed communication among LS ELECTRIC PLC’s.
• Media: UTP/STP category 5.
• Current consumption: 300mA
