H0 5/14D W

ZAR 0.39
Out of stock
SKU
9019010000

Standard wire-end ferrule:

  • Supplied loose in a polybag.
  • Weidmüller's colour code.
  • DIN colour codes.
  • Another colour code.
  • Standard wire-end ferrule, 10 mm × 8 mm, White.

Specification dimensions and weights:

  • Net weight: 0.07 g.

Technical data:

  • Description of article: Wire end ferrule with plastic collar, White.
  • Version: Standard.

Wire-end ferrules:

  • Collar diameter (D2): 2.6 mm.
  • Colour code: DIN.
  • Conductor cross-section: 0.5 mm².
  • Contact surface diameter (D1): 1 mm.
  • Contact surface length (L2): 8 mm.
  • L1 in mm: 14 mm.
  • Metal sleeve thickness (S1): 0.15 mm.
  • Military designation: T 20A 002 A.
  • Plastic collar thickness (S2): 0.25 mm.
  • Stripping length: 10 mm.
  • Wire connection cross section AWG, max.: AWG 20.
More Information
Brand Weidmuller
