Specification dimensions and weights:

• Net weight: 0.08 g.

Technical data:

• Description of article: Wire end ferrule with plastic collar, light blue.
• Version: Standard.

Wire-end ferrules:

• Collar diameter (D2): 2.8 mm.
• Colour code: Miscellaneous.
• Conductor cross-section: 0.75 mm².
• Contact surface diameter (D1): 1.2 mm.
• Contact surface length (L2): 8 mm.
• L1 in mm: 12 mm.
• Metal sleeve thickness (S1): 0.15 mm.
• Military designation: T 20A 004 A.
• Plastic collar thickness (S2): 0.25 mm.
• Stripping length: 10 mm.
• Wire connection cross section AWG, max.: AWG 18.
