H1 0/15 ZH GE SV

ZAR 1.20
Out of stock
SKU
9018530000

Wire-end ferrule:

  • Supplied in multi-pack bag.
  • Weidmüller's colour code.
  • DIN colour codes.
  • Twin wire-end ferrule, 12 mm × 8 mm, Grey.

Specification dimensions and weights:

  • Net weight: 0.16 g.

Technical data:

  • Description of article: Twin wire-end ferrule, yellow.
  • Version: Twin wire-end ferrule.

Wire-end ferrules:

  • Collar diameter (D2): 5.8 mm.
  • Collar width (B): 3.2  mm.
  • Colour code: Weidmueller.
  • Conductor cross-section: 1 mm².
  • Contact surface diameter (D1): 2 mm.
  • Contact surface length (L2): 8 mm.
  • L1 in mm: 15 mm.
  • Metal sleeve thickness (S1): 0.15 mm.
  • Plastic collar thickness (S2): 0.3 mm.
  • Stripping length: 12 mm.
  • Wire connection cross section AWG, max.: AWG 17.
More Information
Brand Weidmuller
