Specification dimensions and weights:

• Net weight: 0.328 g.

Technical data:

• Description of article: Twin wire-end ferrule, blue.
• Version: Twin wire-end ferrule.

Wire-end ferrules:

• Collar diameter (D2): 8 mm.
• Collar width (B): 4.5 mm.
• Colour code: DIN.
• Conductor cross-section: 2.5 mm².
• Contact surface diameter (D1): 2.8 mm.
• Contact surface length (L2): 10 mm.
• L1 in mm: 19 mm.
• Metal sleeve thickness (S1): 0.15 mm.
• Plastic collar thickness (S2): 0.4 mm.
• Stripping length: 13 mm.
• Wire connection cross section AWG, max.: AWG 14
