IE-SW-BL08-7TX-1SC
Specifications:
- Version: Network switch, unmanaged, Fast Ethernet, Number of ports: 7x RJ45, 1 * SC Multi-mode, IP30, -10 °C...60 °C.
- Depth: 70 mm.
- Height: 115 mm.
- Width: 50 mm.
- Storage temperature: -40 °C...85 °C.
- Operating temperature: -10 °C...60 °C.
- Humidity: 5 to 95 % (non-condensing).
Fibred optic transceiver characteristics:
- Transmission rate: 100 Mbps.
- Transceiver type: Multimode.
- Connector type: SC-Duplex.
- Transmission distance, typ.: 5 km.
- Link budget: 12 db.
Wavelength:
- Type: 1,300 nm.
- Wavelength: TX.
- min.: 1,260 nm.
- max.: 1,360 nm.
- Wavelength: RX.
- min.: 1,100 nm.
- max.: 1,600 nm.
Receive power:
- min.: -32 dBm.
- max.: -3 dBm.
Transmission power:
- min.: -20 dBm.
- max.: -10 dBm.
Interfaces:
- Fibre-optic ports: 100BaseFX ports (SC connector), Multimode.
- Function DIP switch: 1x for enabling/disabling the broadcast storm protection.
- LED indicator: PWR1, PWR2, 10/100M (TP-Port), 100M (fibre-optic port).
- Number of ports: 7x RJ45, 1 * SC Multi-mode.
- RJ45 ports: 10/100BaseT(X), auto negotiation, Full-/half-duplex mode, Auto MDI/MDI-X port.
Power supply:
- Connection type: 1 removable 4-pin terminal block.
- Current consumption: 0.17 A at 24 V.
- Overload current protection: 1.1 A.
- Reverse polarity protection: Available.
- Voltage supply: 12/24/48 V DC, 2 redundant inputs.
- Voltage type: DC.
- Voltage min: 9.6V.
- Voltage max: 60V.
Technical data:
- Housing main material: Aluminum.
- Protection degree: IP30.
- Speed: Fast Ethernet.
- Switch: unmanaged.
- Type of mounting: DIN rail.
Brand | Weidmuller |
---|
