LIP 1 5R12 V
Pricing available on request
Insulated pin-cable connector made from PVC or PC/PA:
- Designs that are commercially accessible.
- It is not soldered.
- With a conical entrance funnel.
Specifications:
- Version: cable lug, terminal end, Insulated cable connector.
- Quantity: 100.
- Depth: 5.8 mm
- Width: 23.3 mm.
- Insulated pin-cable connector 1.5 mm² L=12 mm.
Connectors:
- Conductor cross-section, max.: 1.5 mm².
- Conductor cross-section, min.: 0.5 mm².
- Dimension: 12.0 mm.
- Dimension (pin length): 12 mm.
- Identification colour: red.
- Insulation: Available.
- Length 1 (I1): 22 mm.
- Material/plastic: PVC.
- Outside diameter of shaft (d3): 1.9 mm.
- Plastic collar diameter (D): 4.3 mm.
- Plastic collar length (b): 10 mm.
| SKU | 9200460000 |
|---|---|
| Brand | Weidmuller |
