LIS 6M6 V
Pricing available on request
Insulated forked-cable connector made from PVC or PC/PA:
- Designs that are commercially accessible.
- It is not soldered.
- With a conical entrance funnel.
Specifications:
- Version: cable lug, terminal end, Insulated cable connector.
- Quantity: 100.
- Depth: 8 mm
- Width: 32.6 mm.
- Insulated forked-cable connector 6.0 mm² / M6.
Connectors:
- Conductor cross-section, max.: 6 mm².
- Conductor cross-section, min.: 4 mm².
- Connection density (S1): 1 mm.
- Connection length (I): 21.35 mm.
- Dimension: M 6.
- Dimension (bolt): M 6.
- Identification colour: yellow.
- Inside diameter (d1): 6.4 mm.
- Insulation: Available.
- Material/plastic: PVC.
- Outside diameter (d): 12 mm.
- Plastic collar diameter (D): 6.4 mm.
- Plastic collar length (b): 14.15 mm.
| SKU | 9200430000 |
|---|---|
| Brand | Weidmuller |
