Modbus TCP adapter
Features:
- LS PLC SMART I/O XEL-BSSA MODBUS TCP XGT Series RJ-45 2 Port module.
- IEEE 802.3 standard.
- MODBUS/TCP.
- 10/100BASE-TX media.
- Ethernet Twisted pair 2ports (RJ-45).
- 2channels Ethernet MAC.
Specifications:
- I/F:
- Protocol: Modbus TCP.
- Transmission speed: 10/100Mbps.
- Connector: RJ-45 (2ports).
- Topology: Software (BootpServer).
- IP Setup: Bus, Star.
- Max. expansion module: 8ea.
- Max. Digital I/O Point: 256 Points.
- Max. Analog I/O Channel: 32ch (Input 16ch, output 16ch)
- Operating Power:
- Rated voltage: DC 24V.
- Range: DC19.2 – 28.8V.
- Rated Current: 1.5A.
- Insulation: Non-Insulation, Comm, Part Insulation.
| Brand | LS Electric |
|---|
