Features:

• Material: High impact and corrosion resistance polyester reinforced with glass fibres.
• Lid: Fastened with nylon screws, clear or grey lids are available.
• Mounting: Equipped with holes to fasten mounting plates and DIN rails with self-tapping screws.
• Sealing: For improved sealing, use polyurethane in the shape of an O-ring.
• Protection: IP 66 and IP 67 high ingress protection ratings guarantee dust and water resistance.
• Direct fastening through perforations on the back side.
• Weather Resistance: Made to endure harsh chemical and mechanical environments.

Specifications:

• Dimensions:
• Height: 370 mm.
• Width: 300 mm.
• Depth: 175 mm.
• Material: Glass-fibre reinforced polyester.
• Colour: Light Grey.
• Ingress Protection: IP 66 / IP 67.
• Impact Resistance: Up to 7 joules.
• Temperature Range: Suitable for high surrounding temperatures.
• Applications:
• Ideal for enclosing electrical, electro-mechanical, and pneumatic devices.
• Suitable for use in hazardous areas due to its high protection class and robust construction.
• Commonly used for protecting components such as controllers, measuring instruments, and valves.
