Multi-channel Temperature Logger, UT3208+, 8 channels
UT3200+ Series, Multi-channel Temperature Logger:
- 4.3-inch true-colour LCD screen.
- The main parameter is displayed with six digits.
- Supports K, N, E, J, T, R, S, and B thermocouples.
- Test range: -200°C-1800°C.
- Temperature testing resolution is 0.01 °C.
- There are two scan speeds: quick and slow.
- Automatic identification of thermocouple failures.
- Data presentation style is intuitive, with options for column charts and graphs.
- adjustment for cold junctions.
- U-disk storage is supported with a standard USB Host interface and an 8GB U-disk.
- The current settings for file management will not be lost when the power is turned off.
- A standard 2-meter K-type thermocouple can monitor temperatures between 0 and 200°C.
- Temperature upper and lower limit Overrun warning; overrun reading colour changes.
- LAN interface, standard RS-232C, SCPI, and Modbus protocol support.
Specifications:
- UT3200+ Series, Multi-channel Temperature Logger.
- Display mode Direct numerical reading, curve chart, histogram.
- Type Thermocouple: J, K, T, E, S, N, B, R.
- Measuring range -200.0° C-1800.0° C (the range will change with diff errant thermocouple model).
- Resolution 0.01° C.
- Scanning speed Fast, slow.
- Sorting function Build-in data sorting can set upper/lower temperature limit alarm for each channel.
- Alarm function Upper/lower temperature limit alarm.
- User calibration User calibration of each channel is allowed.
- Button functions Lock -- keyboard lock, Print Sc – screenshot.
- Power AC 100-240V 50/60Hz.
- Display mode 4.3-inch LCD screen.
- Product size (W×H×D) 214mm×88.2mm×330.3mm.
| SKU | UT3208-Plus |
|---|---|
| Brand | UNI-T |
