MULTI-RANGE, MULTI-FUNCTION TIMER 110VAC, FUNCTIONS: ON-DELAY, INTERVAL, EQUAL REPEAT, INTERVAL (PULSE CONTROLLED)

ZAR 1,022.47
Out of stock
SKU
T3M110A

Multiple functions (four times as many) 4-time range multi-range:

  • Installing the Electro 11 pin plug-in series of control and timing devices is simple and straightforward since they are designed to fit into a conventional 11 pin base.
  • Multi-function timer based on a microprocessor, with four configurable modes of operation and a time range of 0.3 seconds to 60 hours.
  • Many applications because of the combinations of time intervals and functions.
  • A great degree of accuracy can be attained because of the unit's sophisticated design.
  • The unit has every function that is frequently utilized.
  • After the supply is provided, any adjustments made to the front potentiometer are not recognized.
  • This stops the time range from changing inadvertently.

Features:

  • 10A SPDT delay output repeatable deviation: less than 0.2%.
  • Design based on microprocessors.
  • Duration: 0.3 seconds to 60 hours.
  • 10 A SPDT instantaneous output potentiometer with configurable time setting.
  • LEDs for power supply ON and relay ON.
  • Four function selectable rear DIP switches.
  • Eight timer ranges are selectable via the rear DIP switch.

Specifications:

  • TIME RANGE: 0.3 second - 60hours
  • DESCRIPTION: multi-function, multi-range electronic timer
  • CONTACT: 10A SPDT
  • FUNCTION: On-delay/ Interval/ Equal repeat/ Interval (pulse controlled)/ Instantaneous contact
  • RATED VOLTAGE: 250V
  • MECHANICAL LIFE: 10x106 cycles
  • PROTECTION INDEX IP: IP 20
  • OPERATING TEMPERATURE: -10 to + 50°C
  • STORAGE TEMPERATURE: -50 to + 85°C
  • DIMENSIONS (MM): (H) 92 x (W) 36 x (D) 64

More Information
Brand Electrodev
