MULTI-RANGE, MULTI-FUNCTION TIMER 230VAC, FUNCTIONS: ON-DELAY, INTERVAL, EQUAL REPEAT

ZAR 868.85
Out of stock
SKU
T2M230A

Multiple functions (four times as many) 4-time range multi-range:

  • Installing the Electro 11 pin plug-in series of control and timing devices is simple and straightforward since they are designed to fit into a conventional 11 pin base.
  • Plug-in timers with many functions and a range that cover all frequently used features.
  • The device will reset if the function or time range is altered using the front-mounted controls.

Features:

  • Recurrence deviation: 0.2% Microprocessor-oriented architecture.
  • Range of time: 0.3 seconds to 60 hours.
  • LEDs for the power supply ON and relay ON.
  • Four function selections on the rear DIP switch.
  • Eight timer ranges are selectable via the rear DIP switch.

Specifications:

  • TIME RANGE: 0.3 second - 60hours
  • DESCRIPTION: multi-function, multi-range electronic timer
  • CONTACT: 10A DPDT
  • FUNCTION: On-delay/ Interval/ Equal repeat/ Interval (pulse controlled)
  • RATED VOLTAGE: 250V
  • MECHANICAL LIFE: 10x106 cycles
  • PROTECTION INDEX IP: IP 20
  • OPERATING TEMPERATURE: -10 to + 50°C
  • STORAGE TEMPERATURE: -50 to + 85°C
  • DIMENSIONS (MM): (H) 92 x (W) 36 x (D) 64
More Information
Brand Electrodev
