MULTI-RANGE, MULTI-FUNCTION TIMER 24V AC/DC, FUNCTIONS: ON-DELAY, INTERVAL, EQUAL REPEAT, INTERVAL (PULSE CONTROLLED)
Multiple functions (four times as many) 4-time range multi-range:
- Installing the Electro 11 pin plug-in series of control and timing devices is simple and straightforward since they are designed to fit into a conventional 11 pin base.
- Multi-function timer based on a microprocessor, with four configurable modes of operation and a time range of 0.3 seconds to 60 hours.
- Many applications because of the combinations of time intervals and functions.
- A great degree of accuracy can be attained because of the unit's sophisticated design.
- The unit has every function that is frequently utilized.
- After the supply is provided, any adjustments made to the front potentiometer are not recognized.
- This stops the time range from changing inadvertently.
Features:
- 10A SPDT delay output repeatable deviation: less than 0.2%.
- Design based on microprocessors.
- Duration: 0.3 seconds to 60 hours.
- 10 A SPDT instantaneous output potentiometer with configurable time setting.
- LEDs for power supply ON and relay ON.
- Four function selectable rear DIP switches.
- Eight timer ranges are selectable via the rear DIP switch.
Specifications:
- TIME RANGE: 0.3 second - 60hours
- DESCRIPTION: multi-function, multi-range electronic timer
- CONTACT: 10A SPDT
- FUNCTION: On-delay/ Interval/ Equal repeat/ Interval (pulse controlled)/ Instantaneous contact
- RATED VOLTAGE: 250V
- MECHANICAL LIFE: 10x106 cycles
- PROTECTION INDEX IP: IP 20
- OPERATING TEMPERATURE: -10 to + 50°C
- STORAGE TEMPERATURE: -50 to + 85°C
- DIMENSIONS (MM): (H) 92 x (W) 36 x (D) 64
| Brand | Electrodev |
|---|
