OVER AND UNDER CURRENT MONITOR 0-5A 400VAC
Comparator for Current Windows:
- Installing the Electro 11 pin plug-in series of control and timing devices is simple and straightforward since they are designed to fit into a conventional 11 pin base.
- An accurate UNDER/OVER current window monitoring relay is the WA5.
- The device is perfect for several current monitoring applications because it may be ordered in a variety of AC and DC current ranges.
- Separate potentiometers can be used to change the set points for over and under.
- Additionally, the machine has a latch feature to stop unnoticed malfunctions.
- All units come with a terminating resistor to avoid open circuit in applications that require a CT.
Features:
- Integrated SPDT relay latch facility with 10A output.
- Evaluates individual current input.
- Keeping an eye on the current control relay.
- LED signal indicating excessive or insufficient frequency.
- Limits, both upper and lower individually adjustable.
- Selecting the rear DIP switch for a 10-second startup delay.
- Relay selection via rear DIP switch Within or beyond boundaries.
Current monitor:
- CONTACT: 10A SPDT
- FUNCTION: Over / under
- HYSTERESIS: 5-50%
- RATED VOLTAGE: 250V
- MECHANICAL LIFE: 10x106 cycles
- PROTECTION INDEX IP: IP 20
- OPERATING TEMPERATURE: -10 to + 50°C
- STORAGE TEMPERATURE: -50 to + 85°C
- DIMENSIONS (MM): (H) 92 x (W) 36 x (D) 64
| Brand | Electrodev |
|---|
