Key Features:

• 8 general purpose input channels.
• 2 CJC channels.
• Supports thermocouples, resistance, current, voltage, and RTDs.
• 12-bit resolution.
• 0.1% accuracy.
• 4 mA to 20 mA input current.
• -20 to 125 degrees Celsius input temperature range.
• IP65 protection rating.

Applications:

• Temperature measurement in ovens, furnaces, and other heating and cooling systems.
• Current measurements in motors, generators, and other electrical equipment.
• Voltage measurement in power lines and other electrical circuits.
• Resistance measurement in resistors, sensors, and other electrical components.
• Thermocouple measurement in industrial processes.

Specifications:

• Module Type: Universal Analog.
• Number of Inputs: 8 general purposes.
• Internal Power: 3.3V: 350mA; 5V: 400 mA.
• Number of Slots: 1 (single slot).
• Power Dissipation: 5.4W max.
