PROFInet comms Module PROFIdrive Class1 100mbps speed dual port Full Duplex
Description:
- The SV-iS7 inverter's PROFINET network connectivity is handled by the LS ELECTRIC iS7 PROFINET communication module.
- PROFINET is an IEC 61158 Type 10-compliant communication protocol.
- Full-duplex data transfer, made possible by the PROFINET communication module, provides real-time communication without transmission collisions.
- A PLC sequence program or any master PLC module can be used to control and monitor the iS7 inverter through a PROFINET connection.
- Furthermore, PROFINET is simple to connect to, which supports quicker installation and simpler maintenance.
Specifications:
- PROFINET Protocol support PROFINET IO CC-A.
- PROFIDRIVE Class 1.
- Max. 64 connection points.
- Topology: Line topology.
- Communication speed: 100 Mbps.
- Communication type: Full Duplex.
iS7 Series:
- With its improved V/F control, V/F PG slip compensation, and sensor-less vector control, the iS7 produces more potent performance.
- Focusing on an intuitive user interface and environmentally friendly features, the iS7 has a broad graphic LCD keypad with support for both user and macro groups, as well as an electro-thermal function for motor protection and input/output phase loss protection.
- A speed-precision-driven vector algorithm and a competitive and powerful low-speed torque control are features of iS7 technology.
- 100:1 speed control range.
- Very low torque control capability: actual torque of 150% at 0.1 Hz.
- Maximum torque control capacity inside the range of restoration.
| SKU | SV-IS7-PROFINET |
|---|---|
| Brand | LS Electric |
