Programmable DC Electronic Loads, UTL8211+, (2-Channel, 20A, 200W)
UTL8200+ Series, Programmable DC Electronic Loads:
- UTL8211+: 400W, 150V, 40A.
- UTL8212+: 2200 W, 150 V/2150 V/20 A.
- The four basic modes are CC/CV/CR/CP.
- 1 mV/1 mA resolution is possible.
- Voltage and current sample rate of up to 4.8 MHz
- Battery discharge test with multiple modes.
- List mode with automatic test support.
- Test function for independent short circuits.
- Numerous safeguards, including anti-reverse connections, overvoltage, low voltage, overcurrent, overpower, and overheating.
- SCPI-compatible S232 communication interface.
- Enabling remote operation and monitoring using host computer software.
- Turn off the memory function.
- Fan with intelligent temperature management.
Specifications:
- UTL8200+ Series, Programmable DC Electronic Loads.
- Input ratings 0-40° C Voltage 0-150V.
- CV mode Range 0-150V.
- CC mode Range 0-4A, 0-40A.
- CR mode Range 0.05Ω-7.5KΩ.
- Over-power protection Delay protection, immediate protection.
- Over-current protection Delay protection, immediate protection.
- Over-voltage protection Delay protection, immediate protection.
- Over-temperature protection ≥85° C.
- Interface & protocol RS232, RS485(optional) and SCPI protocol5KΩ.
- Power 110V±10%/220V±10% Frequency 50/60Hz.
- Display 2.8 inches LCD.
- Product net weight 3.42kg.
- Product size (W×H×D) 88mm x 174.6mm x 230mm.
| SKU | UTL8211-Plus |
|---|---|
| Brand | UNI-T |
