UDP3000/S Series, Programmable Linear Power Supplies:

• Maximum power output: 328W.
• Four channel independent output: CH1/CH2: 0-30V/5A, CH3: 0-6V/3A, and CH4: 5V/2A.
• Multiple layers of protection: OCP, OVP, and OTP.
• Excellent load and line regulation.
• Extremely low output ripple and noise.
• Support one-key serial and parallel output functions.
• The 4.3-inch TFT display supports three channels and various parameters at the same time.
• List/delay function for controlling voltage and current output as needed.
• External trigger function for industrial automation control.
• Provide USB host, USB device, LAN, RS232, digital I/O, and other interfaces.
• The waveform display function allows for real-time and dynamic display of the output voltage, current, and power waveforms.
• Intelligent fan speed control can effectively reduce fan noise while in operation.
• Supports file storage and transfer in 10 groups, as well as USB flash read and write.
• High-accuracy display of five-digit voltage and four-digit current, with resolutions of 10 mV / 1 mA and 1 mV / 1 mA.
• Use the keyboard lock feature to guard against errors.
• Support for SCPI remote command control.
