Programmable Switching Power Supplies, UDP6720 100W Basic DC Switching Power Supply 60V/5A
UDP6700 Series, Programmable Switching Power Supplies:
- Full digital control.
- Full-scale, high resolution: 10 mV/1 mA.
- Low ripple and noise.
- Software correction function.
- Minimum overall dimension.
- 2.8-inch LCD display.
- Remote compensation.
- Supports RS232 connectivity.
- Fan intelligent regulation.
- Constant voltage and current output.
- High reliability: overvoltage, overcurrent, and overtemperature protection functions.
- List and delay functions.
- The output is controlled by a switch.
- High-quality, high-cost performance.
- Multiple groups of output voltage/current can be programmed (3 × 200 groups).
Specifications:
- UDP6700 Series, Programmable Switching Power Supplies.
- Channels 1Ch.
- Max V DC 60V.
- Max A DC 5A.
- Watts 100W.
- Max V Resolution 10mV.
- Max A Resolution 1mA.
- Programmable false.
- Warranty 3 years.
- Product Dimensions (L x W x H) 10 in x 6.8 in x 3.5 in.
- Product Weight 6 lb.
| SKU | UDP6720 |
|---|---|
| Brand | UNI-T |
